Gizmo® Bearing and Adaptor Specifications
| Gizmo® Series |
100 |
200 |
300 |
400 |
500 |
600 |
700 |
800 |
| Bearing Number |
B-100 |
B-200 |
B-300 |
B-400 |
B-500 |
B-600 |
B-700 |
B-800 |
| Adaptor Number |
A-1 |
A-2 |
A-3 |
A-4 |
A-5 |
A-6 |
A-7 |
A-8 |
| Gizmo® O.D. C |
.305 |
.580 |
.777 |
.974 |
1.37 |
1.76 |
2.15 |
2.55 |
| Gizmo® Length D |
.593 |
.687 |
.765 |
.812 |
.990 |
1.25 |
1.36 |
1.52 |
| Splash Guard E |
.531 |
.937 |
1.15 |
1.37 |
2.00 |
2.50 |
3.00 |
3.50 |
| Race Width F |
.400 |
.495 |
.615 |
.615 |
.802 |
.965 |
1.080 |
1.240 |
| FlangeG |
.365 |
.650 |
.860 |
1.062 |
1.453 |
1.860 |
2.265 |
2.656 |
| Bearing O.D. H |
.9449 |
1.3780 |
1.8504 |
2.0472 |
2.8346 |
3.3465 |
3.9370 |
4.7244 |
| Bearing Width I |
.406 |
.500 |
.625 |
.625 |
.827 |
.945 |
1.063 |
1.221 |
| Bearing Bore J |
.3150 |
.5906 |
.7874 |
.9843 |
1.3780 |
1.7717 |
2.1654 |
2.5591 |
| Adaptor Width K |
3/4 |
3/4 |
7/8 |
7/8 |
1-1/8 |
1-1/4 |
1-3/8 |
1-1/2 |
| Adaptor O.D. L |
1.249 |
1.624 |
2.124 |
2.374 |
3.124 |
.3.624 |
4.249 |
4.999 |
| Adaptor Flange M |
1-3/4 |
2-1/8 |
2-5/8 |
2-7/8 |
3-5/8 |
4-1/8 |
4-3/4 |
5-1/2 |
| Lock Screw N |
1-3/32 |
1-9/32 |
1-17/32 |
1-21/32 |
2-1/32 |
2-9/32 |
2-19/32 |
2-31/32 |
|
